Product Description
The CBB61 fan capacitor takes heavy-edge metallized Al/Zn film as electrodes and dielectric.It is impregnated with flame-retardant epoxy resin and canned in cubic ABS or PBT plastic case with characteristics of small size,reliable performance and long endurance.
Technical Specifications:
Products Dimensions(mm):
Note:Other specifications,size and terminal outside table are negotiable.
Application:
The CBB61 fan capacitor broadly applied to starting and running of AC single-phase motors at 50Hz(60Hz) frequency for air conditioners' fans,electric fans and exhaust fans etc.at comparatively low rated power.
Our Advantages
1.The company now has 3 high-vacuum coating machines,9 high-gun Slitting machines,6 winding machines and four-gun spray system and other automatic equipment.
2.Our quality management system are certified by ISO9001 and our products have CQC,TUL,UL,VDE and other performance certifications,compliance with EU RoHS direction,with SGS report.
3.The company has a powerful R&D team,a total of nearly 80 patents,inclouding 12 invention patents.It has established a close cooperation relationship with Anhui Province Optoelectronic Appiled Engineering Technoligy Research Center.
4.We have 12 years experience in capacitor industry and 78 industry patents and a number of invention patents.
5.The are modern factories and the world first-class production equipment.
6.7*24 Hours Service,Fast Reply.
Additional info
Standard: GB/T 3667.1 or IEC 60252-1
Origin: China(Mainland)
Export Market: Global
Installation Type: Through Hole
Shape: Squareness
Capacitor Case: Plastic Case
Packing: Export Standard Carton Packing for Capacitors
Delivery Detail: 7~15 days after payment
Port: Shanghai or Ningbo
